多波長橢偏儀 / 鼎昕科技(股)公司

Fast spectroscopic measurement
5 sec for full spectra of {Δ,Ψ} over 350 ~ 840 nm (or 1.5~3.5 eV)

Mobile compact size
28cm (W) x 20cm (D) x 6cm (H), 6kg

Easiest operation in the world
No set-up, No keys to control, Maintenance-free (except lamp), Calibration-free (patented), No effort for alignment (sample faces down), User-friendly operation and analysis software provided

Fixed angle of incidence
70˚±0.5˚

Sample size
(8mm x 8mm) ~ (200mm x 200mm)

Other features
Most ellipsometers require calibration process in each measurement . This is a lengthy and complicated process. SE MF-1000 is calibration & alignment free. This makes fast and accurate measurement

Spectroscopic Ellipsometer
